How to replace the stator in a washing machine?

To replace the stator in the washing machine, follow the below steps:

  • Unplug the washer and disconnect the other supplies from it.
  • Remove the back panel to access the mounting bolt that keeps the rotor intact with the stator.
  • Simply loosen the mounting bolt to detach the rotor (if applicable).
  • Remove the mounting bolts and screws that hold the stator in place.
  • Make sure to disconnect the electrical wire harness carefully.
  • Place the replacement stator and reconnect the wires followed by fixing the mounting screws.
  • Reverse the steps to put the motor and the access panels back where they belong.

Run a test cycle and check if the stator works like before and keeps the motor stable.

Key Takeaways

  • The stator of a washing machine is a stationary part of the machine that helps to generate and maintain the motion of the drum by creating a strong electromagnetic field.
  • The stator is made up of copper coils wrapped around a metal core and is connected to an electrical power source.
  • When an electric current is passed through the coils, it creates an electromagnetic field that produces rotational movement.
  • Make sure to check if the washer is still under warranty or not. If it’s still under warranty then it is best to contact the manufacturer directly as they may cover the replacement of the stator free of charge.
  • Replacement of the stator can be done at home using basic hardware tools and a little know-how on technical stuff.

What is a washing machine stator?

A stator is a device made up of coils and wires that works together with a rotor to generate a strong electromagnetic field for moving the tub in either direction.

So, when an electric current is passed through these coils, it creates an electromagnetic magnetic field that interacts with the magnetic field of the rotor to produce a force that causes the drum to rotate.

It is an extremely important part since the washer won’t spin or agitate if the stator’s windings are damaged.

How does the washer’s stator wear out?

A washing machine stator is typically made of a steel frame or iron core and is wrapped around with insulated copper coils and wires.

They usually wear out slowly, but if the motor is used for a long time, the stator or parts close to it may wear out faster than expected.

Additionally, stators are prone to corrosion due to leakage of moisture or water.

It may also happen that one or more connected components may cause the stator to wear out prematurely.

For example, a bad motor or bearing, a loose drum, or belts that cause too much vibration while the motor is running can all have an effect on the stator.

How to replace the stator in a washing machine?

Replacing the stator in a washing machine can be a bit tricky, but with the right instructions and tools, you can do it yourself.

Let’s take a quick look at the steps to replace the stator so that you can get the washer up and running.

A word of caution

  • The entire process may require you to remove several access panels depending on your washing machine type and model. However, most washing machine stators can be accessed from the back panel itself.
  • Keep your washing machine’s user manual handy and a few hardware tools. The most common tools used in washer repairs are a pair of pliers, a wrench or nut driver, a Phillips head screwdriver, a flathead screwdriver, needle-nose pliers, wire clippers, and electrical tape.
  • Make sure to disconnect the washer from the power source before attempting any repairs. Also, disconnect the water supply and relevant hoses.
  • Move the washer away from the wall so that you can access the back panel easily.

Once you have all the tools you need, you can start replacing the stator in your washing machine.

Step 1: Unplug the washer

Cut the power and water supply to your washing machine so you can move it out of the way and get to the back panel more easily.

Step 2: Remove the access panels

Now, depending on your washing machine type and model, start removing the required access panels to locate the stator.

Most of the time, you can take off the back panel to get to the stator and rotor.

So, remove the access panels accordingly using the screwdrivers or nut drivers, and keep the panels aside.

Step 3: Locate and remove the stator

Once you take off the back panel, you should be able to get to the rotor, which is held in place by a mounting bolt.

Just unscrew the mounting bolt to detach the rotor and access the stator.

Next, remove the electrical wires and wire harness, followed by unscrewing the bolts that keep the stator in place.

Step 4: Replace the stator

Inspect the stator for signs of wear and tear, and if it looks damaged or broken, it will need to be replaced.

Now that the damaged stator is already removed, you can replace it with a new stator that has the same specifications as the original one.

Just mount the stator to its original location, followed by connecting the wire harnesses, and then secure the stator with mounting screws.

After attaching the stator to the washer, replace the rotor and reassemble the washing machine.

Step 5: Reassemble the washer

Once the stator and the rotor are assembled, put the access panels back by reversing the steps.

Once done, shift the washer back to its original place and clear the surrounding floor.

Step 6: Run a test cycle

Finally, reconnect the washer to both the power source and water supply lines to perform a test cycle.

Note: The location of the stator may vary from brand to brand. If you can’t find the stator in your washer, you can look in the user manual or call customer service for help.

Final Thoughts

Many parts, including the stator, will last longer if the washer is serviced on a regular basis.

You will need to buy a new stator from a store that sells parts for washing machines. You will need the model number of your washer to do this.

Once you’ve replaced the stator, your washing machine should be back to working properly like before.

However, if it isn’t, then there may be another problem that needs to be addressed.

Lastly, it’s important to check your washing machine’s warranty before you buy any new parts or try to fix them yourself.

Frequently Asked Questions

When should you replace the stator?

If your washing machine isn’t spinning or draining right, vibrating too much, or making strange sounds, it might be time to check the stator. If you notice any of these issues, it’s important that you narrow down the cause and only replace the stator if it’s actually faulty.

Can I replace the washing machine’s stator on my own?

It is possible to replace the washing machine’s stator if you have experience with appliance repair and feel comfortable working on electrical appliances. However, if you are not confident enough, it is best to leave this job to a professional.

Where can I buy the washing machine’s stator?

You can buy the stator for your washing machine at an appliance parts store near you or online. Make sure to use the model number of your washing machine to get the right part or suitable stator delivered to you.
